LIGHT FIXTURES
Standard runway and taxiway lighting units from Valley Illuminators are the newest design available that meets NASAO/IES lighting specifications.
Description
Using special die-cast aluminum bases, our standard lights provide years and years of trouble-free service.
A number of features make these low-cost units a better choice for your application. No intervening coupler or additional connecting devices are required, resulting in faster installation with no loss in reliability. A simple set screw provides direct, positive connection with the supporting conduit. A specially designed clamp attaches the protective globe to the base without the use of screws or bolts, saving time during installation and service. Valley can adapt to special mounting requirements of your installation, including break-away couplings.
Our runway and taxiway lights are equipped with standard incandescent lamp sockets (Edison base). The protective glass is available in all standard colors.
Installation
Typically, Valley Illuminators' runway/taxiway lights are attached directly to the frangible. A set screw provides positive, trouble-free connection.
Notes
The unique design of our standard light base allows it to be fully weatherproof. Valley Illuminators can adapt these systems to special requirements, including the use of quartz lamps instead of standard incandescents. A specially adapted base can for NASAO/IES installations is also available.
Product List
| PART# | ITEM |
| VL-001W | Fixture complete White |
| VL-002R/G | Fixture complete Red/Green split |
| VL-003B | Fixture complete Blue |
| VL-004R | Fixture complete Red |
| VL-005G | Fixture complete Green |
| VL-006Y | Fixture complete Yellow |
| VL-001LW | Lens only White |
| VL-002LR/G | Lens only Red/Green split |
| VL-003LB | Lens only Blue |
| VL-004LR | Lens only Red |
| VL-005LG | Lens only Green |
| VL-006LY | Lens only Yellow |
Most split color combinations available by special order. All fixtures less bulbs.
| PART# | |
| VL-010C | LENS CLAMP |
| VL-010BC | BREAK-AWAY COLUMN |
| VL-010G | LENS GASKET |
| VL-010SL | TRAFFIC SIGNAL LAMP-40 WATT |
(Contact us for prices)
